Secure digital input/output interface (SDIO)
RM0008
20.9.9
SDIO data control register (SDIO_DCTRL)
Address offset: 0x2C
Reset value: 0x0000 0000
The SDIO_DCTRL register control the data path state machine (DPSM).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9
8
7
6
5
4
3
2
1
0
DBLOCKSIZE
Reserved
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
Bits 31:12
Reserved, always read as 0.
Bit 11 SDIOEN: SD I/O enable functions
If this bit is set, the DPSM performs an SD I/O-card-specific operation.
Bit 10 RWMOD: Read wait mode
0: Read Wait control stopping SDIO_CK
1: Read Wait control using SDIO_D2
Bit 9 RWSTOP: Read wait stop
0: Read wait in progress if RWSTART bit is set
1: Enable for read wait stop if RWSTART bit is set
Bit 8 RWSTART: Read wait start
If this bit is set, read wait operation starts.
Bits 7:4 DBLOCKSIZE: Data block size
Define the data block length when the block data transfer mode is selected:
0000: (0 decimal) lock length = 2 0 = 1 byte
0001: (1 decimal) lock length = 2 1 = 2 bytes
0010: (2 decimal) lock length = 2 2 = 4 bytes
0011: (3 decimal) lock length = 2 3 = 8 bytes
0100: (4 decimal) lock length = 2 4 = 16 bytes
0101: (5 decimal) lock length = 2 5 = 32 bytes
0110: (6 decimal) lock length = 2 6 = 64 bytes
0111: (7 decimal) lock length = 2 7 = 128 bytes
1000: (8 decimal) lock length = 2 8 = 256 bytes
1001: (9 decimal) lock length = 2 9 = 512 bytes
1010: (10 decimal) lock length = 2 10 = 1024 bytes
1011: (11 decimal) lock length = 2 11 = 2048 bytes
1100: (12 decimal) lock length = 2 12 = 4096 bytes
1101: (13 decimal) lock length = 2 13 = 8192 bytes
1110: (14 decimal) lock length = 2 14 = 16384 bytes
1111: (15 decimal) reserved
Bit 3 DMAEN: DMA enable bit
0: DMA disabled.
1: DMA enabled.
502/995
Doc ID 13902 Rev 9
